Hydraulic Pumps for Forklift

Forklift Hydraulic Pump - Commonly used within hydraulic drive systems; hydraulic pumps could be either hydrodynamic or hydrostatic.

A hydrodynamic pump could likewise be considered a fixed displacement pump since the flow throughout the pump for each and every pump rotation cannot be adjusted. Hydrodynamic pumps could also be variable displacement pumps. These types have a more complex composition which means the displacement is capable of being adjusted. Conversely, hydrostatic pumps are positive displacement pumps.

The majority of pumps are functioning within open systems. Typically, the pump draws oil at atmospheric pressure from a reservoir. For this process to function well, it is essential that there are no cavitations occurring at the suction side of the pump. So as to enable this to work correctly, the connection of the suction side of the pump is larger in diameter than the connection of the pressure side. With regards to multi pump assemblies, the suction connection of the pump is normally combined. A common option is to have free flow to the pump, that means the pressure at the pump inlet is at least 0.8 bars and the body of the pump is often in open connection with the suction portion of the pump.

In a closed system, it is okay for there to be high pressure on both sides of the pump. Often, in closed systems, the reservoir is pressurized with 6-20 bars of boost pressure. In the case of closed loop systems, usually axial piston pumps are utilized. Because both sides are pressurized, the pump body requires a separate leakage connection.
