Side Tilt Carriage - There are 4 sizes of hook type blade carriages rated by the blade carriage hoisting capability. Hook type fork carriages have been consistent.
The carriage bar spacing for Class 1 is approximately thirteen inches and the Class 1 carriage is rated to carry cargo up to 2000lbs. The Class 2 carriage is rated to carry cargo up to 5,500lbs with carriage bar spacing of 16 inches. Class III carriages are rated for loads as much as 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for cargo up to 15,500 lbs. The carriage bar spacing for this capacity is twenty five inches.
The carriages for pin type forks may be different depending on the manufacturer. Pin mounted blades may vary by the amount of offset between the blade eye and the blade. Carriage capacity would be determined by the carriage pin size and by the blade size.
